1. Dual – Drive Power for Heavy Loads
Equipped with a 9.5kW drive motor and a 21.5kW lifting motor, the dual – AC drive system delivers strong power, easily carrying a rated load of 3000kg (with a load center distance of 500mm). The no – load travel speed reaches 12km/h, the no – load lifting speed is 330mm/s, and the full – load lifting speed is 140mm/s, efficiently matching the high – frequency transfer and stacking needs of warehouses.
2. Stable Operation and Reliable Safety
Adopting a hydraulic power steering system, it operates lightly and flexibly, with a minimum turning radius of 2900mm, enabling precise steering in narrow passages. The gantry can be adjusted forward and backward, and combined with the rear axle shock – absorption design, it remains stable when driving on uneven roads, effectively reducing cargo bump damage. It is equipped with 21×8 – 9 front wheels and 18×7 – 8 rear wheels, which have strong grip and adapt to various indoor floors.
3. Long – Lasting Battery Life and Low – Cost Operation & Maintenance
Powered by an 80V/300Ah large – capacity battery, a single charge can support 8 – 10 hours of continuous operation, suitable for multi – shift production rhythms. A standard intelligent charger is provided, which can adapt to common industrial power voltages worldwide (such as 110V, 220V, 380V, etc.), convert them into appropriate charging voltages, and charge the battery safely. There is no need to worry about voltage differences in different regions. The whole vehicle has a solid structure, and the design of high – quality oil cylinders and wear – resistant components reduces the frequency of later maintenance. The operation and maintenance cost is 40% lower than that of traditional fuel – powered equipment.
4. Ergonomic Design for Comfort and Efficiency
The ergonomic seat fits the operating posture and is not easy to cause fatigue during long – term operation. The combined display cover clearly shows key information such as power and speed, and the operation interface is intuitive and easy to understand. The whole vehicle has a compact size (length 2850mm × width 1320mm, gantry non – lifting height 2025mm), saving storage space and facilitating turnover in narrow areas.
5. FAQ
- Q: Which scenarios is this forklift suitable for?
A: It is suitable for indoor scenarios such as warehouses and factories, and can efficiently complete the transfer and stacking of goods with a weight of 3 tons or less. - Q: How long can it work on a single charge?
A: It can support 8 – 10 hours of continuous operation in a fully charged state, meeting the needs of regular shifts. - Q: What about charging in different countries with different voltages?
A: The forklift is equipped with a standard intelligent charger, which can adapt to common 110 – 380V industrial power worldwide and convert it into an appropriate charging voltage to ensure safe and convenient charging.
